息子が iPod nano を買って今までのPCでは容量不足なので私のと交換することにした。 EeePC 901-X という少し古めのUMPCなので、外付けディスクを Linux用のディスクに割り当てた。 用途は Live CD作成 マシンかな。
Live CD のイメージ作成に、 以前は metro を使ってましたが、自分しか使わないのでもっと手軽に。
パーティションレイアウトはこんな感じで。
fdisk -l #
ディスク /dev/sdc: 160.0 GB, 160041885696 バイト
ヘッド 255, セクタ 63, シリンダ 19457
Units = シリンダ数 of 16065 * 512 = 8225280 バイト
ディスク識別子: 0x1b155f8d
デバイス ブート 始点 終点 ブロック Id システム
/dev/sdc1 1 9436 75794638+ 83 Linux
/dev/sdc2 9437 9497 489982+ 83 Linux
/dev/sdc3 9498 19457 80003700 83 Linux
/etc/fstab #
/dev/sde1 /boot ext3 noauto,noatime 1 2
/dev/mapper/root / ext4 noatime 0 1
/dev/mapper/swap none swap sw 0 0
/dev/cdrom /mnt/cdrom auto noauto,ro 0 0
/dev/fd0 /mnt/floppy auto noauto 0 0
none /proc/sys/fs/binfmt_misc binfmt_misc defaults 0 0
/var/tmp/jail/portage /usr/portage none bind,rw 0 0
/var/tmp/jail/local-portage /usr/local/portage none bind,rw 0 0
/var/tmp/jail/distfiles /usr/portage/distfiles none bind,rw 0 0
Live CDの起動は、Grubで。 #
# This is a sample grub.conf for use with Genkernel, per the Gentoo handbook
# http://www.gentoo.org/doc/en/handbook/handbook-x86.xml?part=1&chap=10#doc_chap2
# If you are not using Genkernel and you need help creating this file, you
# should consult the handbook. Alternatively, consult the grub.conf.sample that
# is included with the Grub documentation.
#color white/red black/red
#splashimage=/boot/splash.xpm.gz
splashimage=/boot/grub/bt4.xpm.gz
default 0
timeout 30
password --md5 $1$jBaL5/$pIpowSTX5ip2pDXllzSd90
title=Gentoo Linux (2.6.31-pentoo-r2)
root (hd0,0)
kernel /boot/kernel-genkernel-x86-2.6.31-pentoo-r2 root=/dev/ram0 \
crypt_root=/dev/sdc3 \
ramdisk=8192 quiet CONSOLE=/dev/tty1 \
resume=swap:/dev/mapper/swap init=/linuxrc
initrd /boot/initramfs-genkernel-x86-2.6.31-pentoo-r2
# -- Backtrack4
title BT-4
root (hd0,0)
kernel /boot/bt4/vmlinuz BOOT=casper boot=casper persistent rw quiet
initrd /boot/bt4/initrd.gz
title=USB stick Pentoo
root (hd0,0)
kernel /boot/kernel-genkernel-x86-2.6.31-pentoo-r2 root=/dev/ram0 \
root=/dev/ram0 cdroot aufs \
init=/linuxrc max_loop=256 nokeymap \
looptype=squashfs loop=/image/root-20091113.squashfs
initrd /boot/initramfs-genkernel-x86-2.6.31-pentoo-r2
#title USB stick Pentoo
#root (hd0,0)
#kernel /boot/pentoo/pentoo \
# root=/dev/ram0 cdroot aufs changes=/dev/sde2 \
# init=/linuxrc max_loop=256 nokeymap \
# looptype=squashfs loop=/pentoo/image-2009.squashfs
#initrd /boot/pentoo/pentoo.igz
#title USB stick Pentoo
#root (hd0,0)
#kernel /boot/kernel-genkernel-x86-2.6.29-pentoo-r2 \
# root=/dev/ram0 cdroot aufs changes=/dev/sdc2 \
# init=/linuxrc max_loop=256 nokeymap \
# looptype=squashfs loop=/pentoo/image.squashfs
#
#initrd /boot/initramfs-genkernel-x86-2.6.29-pentoo-r2
title grub-install
lock
install (hd0,0)/boot/grub/stage1 d (hd0) (hd0,0)/boot/grub/stage2 p (hd0,0)/boot/grub/grub.conf
title Other Operating System - Microsoft Windows XP
lock
rootnoverify (hd0,0)
makeactive
chainloader +1
# vim:ft=conf:
Live CDの作成は chroot環境で。 #
- CHROOT環境設定[[http://github.com/ac1965/config-ac1965/blob/master/etc/skel/script/in.sh][]]
- []][[http://github.com/ac1965/config-ac1965/blob/master/etc/skel/script/chroot.sh]コンパイル用[[http://github.com/ac1965/config-ac1965/blob/master/etc/skel/script/chroot.sh][]]
- []][[http://github.com/ac1965/config-ac1965/blob/master/etc/skel/script/out.sh]CHROOT解除
- MAKE ROOT-IMAGE
こんな感じで使います。CHROOTは私の環境では、"/var/tmp/jail/squashfs-root"
# ./in.sh
# cp chroot.sh ${CHROOT}/tmp
# chroot ${CHROOT} /tmp/chroot.sh
# ./out.sh
# ./mkrootimg.sh
